Basic Info.
Model NO.
WD60
Customized Support
OEM
Function
Tack Mode, Step Delay
Reaction Time
0.00004 Sec
Application
All Welding, Cutting, Grinding
Transport Package
Shipping Carton
Specification
110 x 90 x 9mm
HS Code
8543709990
Production Capacity
200000pieces/Year
Product Description
This product take our best and latest technonlogy of Tack Mode, Step Delay with our independent 6th Genations ships to bring best using experience and welding protection for users .
Step Delay Features introduction and advantage
During the welding, ADF is normally in the dark state 13, 14 or dark state 10, 11 to protect the welder's eyesfrom strong welding arc, when the welding work completed welding arc disappeared, the normal ADF shade will directly change from dark state to bright state in 0.1 to 1 second short time , which make the eyes needs to adapt to the extreme brightness change from dark to bright in very short seconds and make eyes discomfort. The step delay function perfectly solves this pain point, after the end of welding, ADF is not directly changed from dark state to bright state, but first change from dark state to shade 5, and then turns to light state, so that the eye has an adaptation process and feels more comfortable
Tack Mode Features introduction and advantage
Generally, during spot welding, the welding arc will frequently switch between dark state and light state i n a short period of time, so that the ADF filter also frequently switches between dark state and light state, making people eyes discomfort. Tack Mode function perfectly solves this pain point by making Shade5 to be the convert shade, when the spot welding arc disappears, ADF is not directly switched to the light stat e, but to shade 5, which greatly reduces the discomfort of the eyes caused by the big change of brightness and darkness, and also ensures the clarity of the view during welding work
Step Delay Features introduction and advantage
During the welding, ADF is normally in the dark state 13, 14 or dark state 10, 11 to protect the welder's eyesfrom strong welding arc, when the welding work completed welding arc disappeared, the normal ADF shade will directly change from dark state to bright state in 0.1 to 1 second short time , which make the eyes needs to adapt to the extreme brightness change from dark to bright in very short seconds and make eyes discomfort. The step delay function perfectly solves this pain point, after the end of welding, ADF is not directly changed from dark state to bright state, but first change from dark state to shade 5, and then turns to light state, so that the eye has an adaptation process and feels more comfortable
Tack Mode Features introduction and advantage
Generally, during spot welding, the welding arc will frequently switch between dark state and light state i n a short period of time, so that the ADF filter also frequently switches between dark state and light state, making people eyes discomfort. Tack Mode function perfectly solves this pain point by making Shade5 to be the convert shade, when the spot welding arc disappears, ADF is not directly switched to the light stat e, but to shade 5, which greatly reduces the discomfort of the eyes caused by the big change of brightness and darkness, and also ensures the clarity of the view during welding work
ADF Model | WD60 |
Optical Class | 1/1/1/2 |
Viewing Area | 98 x 62mm /3.86" x 2.5" |
Cartridge Size | 110 x 90 x 9mm / 4.33" x 3.54" x 0.28" |
UV/IR Protection | Permanent Shade DIN 13 |
Light State | Shade DIN 3 |
Dark State | Variable Shade 5-8/9-13 |
Sensors | 4 |
Grinding | Shade DIN 3 |
Sensitivity Control | DIGITAL(1-6) |
Reaction Time (swithing time) | 0.00004 sec |
Delay Control (Time from dark to light) | 0.1-0.9s/2-step/Tack mode |
Digital Display | YES |
Battery Type | 1×CR2450 (Replaceable) |
Solar Cell | YES |
Power On/Off | Fully Automatic |
TIG Rating | >2Amp |
Standard | EN379 CE / ANSI Z87.1 / Z94.3 |
Well PPE Co., Ltd. has welding helmet and auto darken filter R & D and manufacturing experience for 20 years, our products are exported to Europe,the United States and also other welding protection market to provide high-quality protection for the local welders and got customers unanimous praise.
We has been focusing on product research and development and committed to providing better security for welders, we have made a major breakthrough in ADF technology this year after years of efforts, and successfully developed ADF autoshade, step delay, shade lock, tack mode etc. functions, we combine these technologies with our self-developed chips, and is the advance manufacturer on the market currently which can apply these advanced technologies to the single same ADF products.We can also provide OEM and OEM as per customer requirement .
Welcome customers to enquire and purchase, let us work together to contribute our own light and heat to the welding protection industry.
